EL506 Pentode Vacuum Tube

Pentode6.3V / 0.8AMagnovalSPICE

SourceEL506 datasheet (beam power, not strict pentode)Reviewed2026-05-29StatusDataModelCalcModelKoren pentodePDF

Power pentode delivering up to 19W in pentode, UL, or triode mode

Datasheet ↗SPICE

EL506 — Philips — pentode vacuum tube — (1962)

25.0kΩ

10.2mA/V

9.0pF

0.4pF

4.00pF

GAIN0%

POWER48%

DRIVE75%

LINEARITY75%

SPECIFICATIONS

Heater6.3 V · 0.8 A

Max Plate Voltage550 V

Pa max19 W

Gain Factor—

gm10.2 mA/V

rp25.0 kΩ

Inter-electrode capacitances

Cgk9 pF

Cgp0.4 pF

Cpk4 pF

PinoutMagnoval

Era1962

RarityModerate

HEATER6.3V / 0.8A

MAX PLATE550V / 19W

BASEmagnoval

Source datasheets

1 manufacturer datasheets cross-checked for EL506

1 verified

EXECUTIVE SUMMARY

The EL506 is a indirectly-heated pentode from Philips, introduced around 1962. Commonly used in power applications. Magnoval power.
