What is the EL95 vacuum tube?

The EL95 is a pentode vacuum tube designed for power applications. Compact output..

What is a EL95 substitute or equivalent?

Direct equivalents to the EL95 include 6DL5. These share the same pinout and operating envelope, so they can usually be swapped without circuit changes — though batch-to-batch variations between manufacturers (NOS vs current production) may shift the sonic character noticeably.

What are the key specifications of the EL95?

Amplification factor μ ≈ 17, transconductance gm ≈ 5 mA/V, plate resistance rp ≈ 80.0 kΩ, max plate voltage 300 V, max plate dissipation 6 W, heater 6.3 V / 0.2 A.

Is the EL95 still in production?

Production status varies by year and manufacturer. The current Amperatubes catalog classifies the EL95 as Common availability. NOS (new-old-stock) examples from RCA, Mullard, Tung-Sol, GE, Sylvania and Telefunken trade among collectors; modern production where it exists comes mostly from JJ Electronic, Electro-Harmonix, Tung-Sol (New Sensor), Genalex, and a handful of small-batch makers.

What does the EL95 sound like?

Compact output.. Sonic character also depends heavily on the circuit operating point, the surrounding tubes in the stage, and the output transformer when present — use the interactive loadline calculator on this page to explore the trade-offs.

EL95 Pentode Vacuum Tube

Also known as 6DL5

Small-signal pentode for low-noise voltage amplification

PentodeHeater 6.3 V · 0.2 A7-pin MiniaturePhilips 1958

Plate dissipation: 6W
Max plate voltage: 300V
Max screen voltage: 300V
Max cathode current: 35mA
Transconductance: 5mA/V

EL95

Characteristics

Datasheet values, once each. Every value cites its sheet.

HeaterIndirectly heated

Specifications of EL95 — Heater
Heater voltageVh	6.3 V
Heater currentIh	0.2 A

Limiting valuesDatasheet maximum ratings — not to be exceeded

Specifications of EL95 — Limiting values
Plate voltageVa max	300 V
Screen voltageVg2 max	300 V
Plate dissipationPa max	6 W
Cathode currentIk max	35 mA
Grid resistorRg1 max	2 MΩ
Peak plate voltageVao	550 V

Mechanical

Specifications of EL95 — Mechanical
Base	7-pin Miniature
Rarity	Common
Pinout

Small signalDatasheet parameters at the reference operating point — not limits

Specifications of EL95 — Small signal
Transconductance	5 mA/V
Plate resistance	80 kΩ
Amplification factor	17

Capacitances

Specifications of EL95 — Capacitances
Input	5.3 pF
Grid–plate	0.4 pF
Output	3.5 pF

Charactereditorial reading, not a measurement

Specifications of EL95 — Character
Gain	17%
Power	15%
Drive	20%
Linearity	92%

datasheet cited · model or editorial reading · catalogue value, no citation attached yet · nothing invented

Using this tube

No interactive loadline model for this tube yet — download a SPICE model below to simulate it in LTspice or ngspice.

Replace or compare

Sources

By Jean-Michel Falligan DevergneReviewed May 29, 2026Source : EL95/6DL5 datasheet (vacuumtubes.io · r-type.org)

Manufacturer datasheets

2 manufacturer datasheets cross-checked for EL952 verified

EL95 DatasheetLocal mirror · PDF

SPICE models

Revision and verification status

Source: EL95/6DL5 datasheet (vacuumtubes.io · r-type.org)
Reviewed: 2026-05-29
Status: DataModelCalc
Model: under review

Context

The EL95 is a indirectly-heated pentode from Philips, introduced around 1958. It provides a gain factor (μ) of 17 with 80.0kΩ plate resistance. Commonly used in power applications. Compact output.

History

Introduced: 1958
Manufacturer: Philips
Era: Golden Age
